Bidirectional DC‑DC module with DSP control, high‑frequency isolated soft‑switching resonant technology, high efficiency, automatic charge/discharge switching, parallel operation, current sharing, and RS485 communication. Widely used in battery formation, DC charging, storage, burn‑in, and more – the preferred choice for bidirectional power applications.
This bidirectional DC‑DC module features seamless source‑load mode switching and soft‑switching technology with up to 95% conversion efficiency. Its plug‑in modular design facilitates easy installation and maintenance. The module supports source CC/CV modes, load CC/CV/CP/CR modes, and automatic source‑load switching in CV mode. Comprehensive protection functions cover overcurrent, overvoltage, overload, overtemperature, undervoltage, short circuit, and fan failure. Fully isolated RS485 and CAN interfaces enable robust communication, while full digital control ensures high accuracy, low ripple, low noise, and excellent cost‑effectiveness.
